French Technology
French Standard

First overheat protection time: ≥8 min
Quincuncial shaft

Learn more about45mm Mechanical Tubular MotorParameter >

Look over 45mm Mechanical Tubular Motor Other models parameters

  • K45-TP-20-18
  • K45-TP-15-28
  • K45-TP-20-28
  • K45-TP-30-18
  • K45-TP-40-18
  • K45-TP-50-12
Explanation

K45-TP-20-18

K: Tubular motor

45:External diameter 45mm

TP:No receiver + Mechanical limit

20:Torque 20N*m

18: 18 rpm

Model Size

Length:559mm

Diameter:45mm

Feature function

French Technology and Standard

First overheat protection time: ≥8 min

Input Voltage: AC 220V/110V

Quincuncial shaft

Paired pipe: φ60 octagonal, φ50 round, φ63 & φ85 groove

Product parameter

Rated torque 20 N*m

Input voltage AC 220V/110V

Rated speed 18 rpm

Power 150W

Noise index ≤45dB

Protection class IP44

Rated Frequency (Hz) 50/60

Explanation

K45-TP-15-28

K: Tubular motor

45:External diameter 45mm

TP:No receiver + Mechanical limit

15:Torque 15N*m

28: 28 rpm

Model Size

Length:559mm

Diameter:45mm

Feature function

French Technology and Standard

First overheat protection time: ≥8 min

Input Voltage: AC 220V/110V

Quincuncial shaft

Paired pipe: φ60 octagonal, φ50 round, φ63 & φ85 groove

Product parameter

Rated torque 15 N*m

Input voltage AC 220V/110V

Rated speed 28 rpm

Power 150W

Noise index ≤45dB

Protection class IP44

Rated Frequency (Hz) 50/60

Explanation

K45-TP-20-28

K: Tubular motor

45:External diameter 45mm

TP:No receiver + Mechanical limit

20:Torque 20N*m

28: 28 rpm

Model Size

Length:579mm

Diameter:45mm

Feature function

French Technology and Standard

First overheat protection time: ≥8 min

Input Voltage: AC 220V/110V

Quincuncial shaft

Paired pipe: φ60 octagonal, φ50 round, φ63 & φ85 groove

Product parameter

Rated torque 20 N*m

Input voltage AC 220V/110V

Rated speed 28 rpm

Power 180W

Noise index ≤45dB

Protection class IP44

Rated Frequency (Hz) 50/60

Explanation

K45-TP-30-18

K: Tubular motor

45:External diameter 45mm

TP:No receiver + Mechanical limit

30:Torque 30N*m

18: 18 rpm

Model Size

Length:579mm

Diameter:45mm

Feature function

French Technology and Standard

First overheat protection time: ≥8 min

Input Voltage: AC 220V/110V

Quincuncial shaft

Paired pipe: φ60 octagonal, φ50 round, φ63 & φ85 groove

Product parameter

Rated torque 30 N*m

Input voltage AC 220V/110V

Rated speed 18 rpm

Power 180W

Noise index ≤45dB

Protection class IP44

Rated Frequency (Hz) 50/60

Explanation

K45-TP-40-18

K: Tubular motor

45:External diameter 45mm

TP:No receiver + Mechanical limit

40:Torque 40N*m

18: 18 rpm

Model Size

Length:589mm

Diameter:45mm

Feature function

French Technology and Standard

First overheat protection time: ≥8 min

Input Voltage: AC 220V/110V

Quincuncial shaft

Paired pipe: φ60 octagonal, φ50 round, φ63 & φ85 groove

Product parameter

Rated torque 40 N*m

Input voltage AC 220V/110V

Rated speed 18 rpm

Power 200W

Noise index ≤45dB

Protection class IP44

Rated Frequency (Hz) 50/60

Explanation

K45-TP-50-12

K: Tubular motor

45:External diameter 45mm

TP:No receiver + Mechanical limit

50:Torque 50N*m

12: 12 rpm

Model Size

Length:589mm

Diameter:45mm

Feature function

French Technology and Standard

First overheat protection time: ≥8 min

Input Voltage: AC 220V/110V

Quincuncial shaft

Paired pipe: φ60 octagonal, φ50 round, φ63 & φ85 groove

Product parameter

Rated torque 50 N*m

Input voltage AC 220V/110V

Rated speed 12 rpm

Power 200W

Noise index ≤45dB

Protection class IP44

Rated Frequency (Hz) 50/60
