Easier than you can think

Technology is endless, easier and simplifying,
As the only one who works with military FSK
868 MHZ FM technology, N09 curtain motor
can be installed above track.Fully compatible
with smart home system.

Learn more aboutN09 Curtain MotorParameter >

Look over N09 Curtain Motor Other models parameters

  • N09-EL-1
  • N09-EL-2
  • N09-3A-1
  • N09-3A-2
Explanation

N09-EL-1

N: represent opening and closing curtains motor

09: Represent Shape Code

EL: Represent electronic limit + Receiver

1: Represent 1N torque

Model Size

Height: 288mm

Width: 73mm

Thickness: 54mm

Feature function

AC intelligent switching power supply wide voltage design

Motor mounted on stealth installation design

Integration of the overall shape design

Built-in wire design three alignment method

super-quiet design

Built-in receiver

Automatic electronic memory and limit function

Compatible with a variety of smart home control system

Unique military-grade FSK868 FM

Wireless, dry contact control

Stable operation

Manual pulling without power

Starter by itself by pulling 20cm

Full metal shaft design

S type runner combination

Long working life, super-stable

Product parameter

Torque 1N.m

Speed 20cm / s

Access voltage 200V-230V

Working voltage 200V-230V

Power 50W

Rated speed 110rpm

Straight track splice length 12m

Electric Weight 1.2kg

Explanation

N09-EL-2

N: represent opening and closing curtains motor

09: Represent Shape Code

EL: Represent electronic limit + Receiver

2: Represent 2N torque

Model Size

Height: 288mm

Width: 73mm

Thickness: 54mm

Feature function

AC intelligent switching power supply wide voltage design

Motor mounted on stealth installation design

Integration of the overall shape design

Built-in wire design three alignment method

super-quiet design

Built-in receiver

Automatic electronic memory and limit function

Compatible with a variety of smart home control system

Unique military-grade FSK868 FM

Wireless, dry contact control

Stable operation

Manual pulling without power

Starter by itself by pulling 20cm

Full metal shaft design

S type runner combination

Long working life, super-stable

Product parameter

Torque 2N.m

Speed 20cm / s

Access voltage 200V-230V

Working voltage 200V-230V

Power 80W

Rated speed 110rpm

Straight track splice length 12m

Electric Weight 1.4kg

Explanation

N09-3A-1

N: represent opening and closing curtains motor

09: Represent Shape Code

3A: Represent electronic limit + Receiver + strong current

1: Represent 1N torque

Model Size

Height: 288mm

Width: 73mm

Thickness: 54mm

Feature function

AC intelligent switching power supply wide voltage design

Motor mounted on stealth installation design

Integration of the overall shape design

Built-in wire design three alignment method

super-quiet design

Built-in receiver + strong current

Automatic electronic memory and limit function

Compatible with a variety of smart home control system

Unique military-grade FSK868 FM

Wireless, dry contact control

Stable operation

Manual pulling without power

Starter by itself by pulling 20cm

Full metal shaft design

S type runner combination

Long working life, super-stable

Product parameter

Torque 1N.m

Speed 20cm / s

Access voltage 200V-230V

Working voltage 200V-230V

Power 50W

Rated speed 110rpm

Straight track splice length 12m

Electric Weight 1.2kg

Explanation

N09-3A-2

N: represent opening and closing curtains motor

09: Represent Shape Code

3A: Represent electronic limit + Receiver + strong current

2: Represent 2N torque

Model Size

Height: 288mm

Width: 73mm

Thickness: 54mm

Feature function

AC intelligent switching power supply wide voltage design

Motor mounted on stealth installation design

Integration of the overall shape design

Built-in wire design three alignment method

super-quiet design

Built-in receiver + strong current

Automatic electronic memory and limit function

Compatible with a variety of smart home control system

Unique military-grade FSK868 FM

Wireless, dry contact control

Stable operation

Manual pulling without power

Starter by itself by pulling 20cm

Full metal shaft design

S type runner combination

Long working life, super-stable

Product parameter

Torque 2N.m

Speed 20cm / s

Access voltage 200V-230V

Working voltage 200V-230V

Power 80W

Rated speed 110rpm

Straight track splice length 12m

Electric Weight 1.4kg
